Mastering Haas Lathe Settings: Complete CNC Configuration Guide

Complete list of Haas settings for CNC machinists who work on Haas Lathe machines.

Haas Settings Introduction

Haas Settings are Haas machine conditions that have an affect on machine operation. In general, settings allow the operator or setup person to lock out, turn on or specify functions.

Haas Settings

Haas Lathe Settings

• 1 – Auto Power Off Timer
• 2 – Power Off At M30
• 3 – 3D Graphics
• 4 – Graphics Rapid Path
• 5 – Graphics Drill Point
• 6 – Front Panel Lock
• 7 – Parameter Lock
• 8 – Prog Memory Lock
• 9 – Dimensioning
• 10 – Limit Rapid At 50%
• 11 – Baud Rate Select
• 12 – Parity Select
• 13 – Stop Bit
• 14 – Synchronization
• 16 – Dry Run Lock Out
• 17 – Opt Stop Lock Out
• 18 – Block Delete Lock Out
• 19 – Feedrate Override Lock
• 20 – Spindle Override Lock
• 21 – Rapid Override Lock
• 22 – Can Cycle Delta Z
• 23 – 9xxx Progs Edit Lock
• 24 – Leader To Punch
• 25 – EOB Pattern
• 26 – Serial Number
• 28 – Can Cycle Act w/o X/Z
• 31 – Reset Program Pointer
• 32 – Coolant Override
• 33 – Coordinate System
• 36 – Program Restart
• 37 – RS-232 Data Bits
• 38 – Aux Axis Number
• 39 – Beep at M00, M01, M02, M30
• 41 – Add Spaces RS232 Out
• 42 – M00 After Tool Change
• 43 – Cutter Comp Type
• 44 – Min F in Radius TNC %
• 45 – Mirror Image X-axis
• 47 – Mirror Image Z-axis
• 50 – Aux Axis Sync
• 51 – Door Hold Switch Override (Safety Switch Override)
• 52 – G83 Retract Above R
• 53 – Jog w/o Zero Return
• 54 – Aux Axis Baud Rate
• 55 – Enable DNC from MDI
• 56 – M30 Restore Default G
• 57 – Exact Stop Canned X-Z
• 58 – Cutter Compensation
• 59 – Probe Offset X+
• 60 – Probe Offset X-
• 61 – Probe Offset Z+
• 62 – Probe Offset Z-
• 63 – Tool Probe Width
• 64 – T. OFS Meas Uses Work
• 65 – Graph Scale (Height)
• 66 – Graphics X Offset
• 68 – Graphics Z Offset
• 69 – DPRNT Leading Spaces
• 70 – DPRNT Open/Clos DCode
• 72 – Can Cycle Cut Depth
• 73 – Can Cycle Retraction
• 74 – 9xxxx PROGS Trace
• 75 – 9xxx PROGS Single BLK
• 76 – Foot Pedal Lock Out
• 77 – Scale Integer F
• 81 – Tool at Auto Off
• 82 – Language
• 83 – M30 Resets Override
• 84 – Tool Overload Action
• 85 – Max Corner Rounding
• 86 – Thread Finish Allowance
• 87 – TNN Resets Override
• 88 – Reset Resets Overrides
• 90 – Graph Z Zero Location
• 91 – Graph X Zero Location
• 92 – Chuck Clamping
• 93 – Tailstock X Clearance
• 94 – Tailstock Z Clearance
• 95 – Thread Chamfer Size
• 96 – Thread Chamfer Angle
• 97 – Tool Change Direction
• 98 – Spindle Jog RPM
• 99 – Thread Minimum Cut
• 100 – Screen Saver Delay
• 101 – Feed Overide -> Rapid
• 102 – C Axis Diameter
• 103 – CYC Start/FH Same Key
• 104 – Jog Handl to SNGL BLK
• 105 – TS Retract Distance
• 106 – TS Advance Distance
• 107 – TS Hold Point
• 109 – Warmup Time in Min.
• 110 – Warmup X Distance
• 112 – Warmup Z Distance
• 113 – Tool Change Method
• 114 – Conveyor Cycle Time (Minutes)
• 115 – Conveyor On-time (Minutes)
• 118 – M99 Bumps M30 CNTRS
• 119 – Offset Lock
• 120 – Macro VAR Lock
• 121 – Foot Pedal TS Alarm
• 122 – SS Chuck Clamping
• 131 – Auto Door
• 132 – Jog or Home Before TC
• 133 – Repeat Rigid Tap
• 134 – Connection Type
• 135 – Network Type
• 136 – Server
• 137 – Username
• 138 – Password
• 139 – Path
• 140 – TCP/IP ADDR
• 141 – Subnet Mask
• 142 – Offset CHNG Tolerance
• 143 – Machine Data Collect
• 144 – Feed Overide->Spindle
• 145 – TS at Part for CS
• 156 – Save Offset with PROG
• 157 – Offset Format Type
• 158 159 160 – Screw Thermal COMP%
• 162 – Default To Float
• 163 – Disable .1 Jog Rate
• 164 – Powerup SP Max RPM
• 165 – SSV Variation
• 166 – SSV CYCLE (0.1) SECS
• 167-186 Periodic Maintenance
• 187 – Machine Data Echo
• 196 – Conveyor Shutdown
• 197 – Coolant Shutdown
• 198 – Background Color
• 199 – Backlight Timer
• 201 – Show Only Work and Tool Offsets In Use
• 202 Live Image Scale (Height)
• 203 Live Image X Offset
• 205 Live Image Z Offset
• 206 Stock Hole Size
• 207 Z Stock Face
• 208 Stock OD Diameter
• 209 Length of Stock
• 210 Jaw Height
• 211 Jaw Thickness
• 212 Clamp Stock
• 213 Jaw Step Height
• 214 Show Rapid Path Live Image
• 215 Show Feed Path Live Image
• 216 – Servo and Hydraulic Shutoff
• 217 Show Chuck Jaws
• 218 Show Final Pass
• 219 Auto Zoom to Part
• 220 TS Live Center Angle
• 221 Tailstock Diameter
• 222 Tailstock Length
• 224 Flip Part Stock Diameter
• 225 Flip Part Stock Length
• 226 SS Stock Diameter
• 227 SS Stock Length
• 228 SS Jaw Thickness
• 229 SS Clamp Stock
• 230 SS Jaw Height
• 231 SS Jaw Step Height
• 232 G76 Default P Code
• 233 SS Clamping Point
• 234 SS Rapid Point
• 235 SS Machine Point
• 236 FP Z Stock Face
• 237 SS Z Stock Face
• 238 – High Intensity Light Timer (minutes)
• 239 – Worklight Off Timer (minutes)
• 240 Tool Life Warning
• 241 Tailstock Hold Force
• 242 – Air Water Purge Interval (minutes)
• 243 – Air Water Purge On-Time (seconds)
• 900 – CNC Network Name
• 901 Obtain Address Automatically
• 902 IP Address
• 903 – Subnet Mask
• 904 – Gateway
• 905 – DNS Server
• 906 – Domain/Workgroup Name
• 907 – Remote Server Name
• 908 Remote Share Path
• 909 – User Name
• 910 – Password
• 911 – Access to CNC Share (Off, Read, Full)
• 912 – Floppy Tab Enabled
• 913 – Hard Drive Tab Enabled
• 914 – USB Tab Enabled
• 915 – Net Share
• 916 – Second USB Tab Enabled
