Fanuc G43, G44 & G49: Mastering Tool Length Compensation
G43 Tool Length Compensation positive
With G43 a value from the offset register (OFFSET) can be called up and added to tool length.
To all following Z movements (with active XY plane – G17) in the program this value will be added.
Programming
N... G43 H...
Example
N... G43 H05
The value, which is written into the register under H05, will be added to all following Z movements as tool length.
G44 Tool Length Compensation negative
With G44 a value from the offset register (OFFSET) can be called up and subtracted from tool length.
To all following Z movements (with active XY plane – G17) in the program this value will be subtracted from.
Programming
N... G44 H...
G49 Cancel Tool Length Compensation
The positive (G43) or negative (G44) shift will be cancelled.
Programming
N... G49
