In manufacturing, compressed air is often dubbed the "fourth utility"—the reliable power source behind pneumatic tools and equipment essential to production. Yet water, oil, dust, and other contaminants can compromise the purity of that air, jeopardizing product safety and integrity.

Understanding ISO 8573‑1:2010 is key. This internationally recognized standard classifies air purity, ensuring your compressed air meets the exact specifications required by your application and industry. This guide decodes ISO 8573‑1 so you can stay compliant with confidence.

What Is ISO 8573‑1:2010?

ISO 8573‑1:2010 is the cornerstone for manufacturers and laboratories when classifying air purity. While the standard spans nine parts, Part 1 is the most critical for production, defining permissible limits for solid particulates, water, and oil in compressed air. These three contaminants dictate whether your air can safely feed critical processes.

The Three Pillars of Air Purity

ISO 8573‑1 measures each contaminant with specific criteria:

• Solid Particulates: Classified by micron size (0.1–5 µm) and particle count per cubic meter.
• Water: Expressed as pressure dew point (PDP) or liquid water content. Higher classes tolerate moderate moisture, while Class 1 demands ultra‑dry air (≤ ‑70 °C).
• Oil: Covers total liquid oil, aerosols, and vapors. Purity ranges from ≤ 0.01 mg/m³ in Class 1 to > 5 mg/m³ in lower classes.

Download JHFOSTER’s comprehensive ISO 8573‑1 PDF for detailed limits by class.

How to Read an Air Quality Specification

When specifying air purity, ISO 8573‑1:2010 is followed by a three‑digit class. Each digit represents a contaminant group:

• First Digit: Solid particulate requirement.
• Second Digit: Water requirement.
• Third Digit: Total oil requirement.

For example, ISO 8573‑1:2010 1.2.1 means:

• Class 1 Particulate: ≤20 000 particles/m³ in the 0.1–0.5 µm range, ≤400 particles/m³ in the 0.5–1 µm range, and ≤10 particles/m³ in the 1–5 µm range.
• Class 2 Water: PDP of ‑40 °F (‑40 °C) or better, with no liquid water allowed.
• Class 1 Oil: ≤0.01 mg/m³ total oil (liquid, aerosol, and vapor).

The Truth About Class 0 Air Quality

Class 0 does not mean “zero contamination.” Instead, it signifies a user‑defined specification that is stricter than Class 1, agreed upon by the equipment manufacturer and the end‑user. Even an oil‑free compressor can fail to deliver Class 0 if intake air is contaminated, so additional purification equipment is usually required at the point of use.

Industry‑Specific Air Quality Requirements

ISO 8573‑1 assigns specific purity classes to various sectors. Typical examples include:

• General industry: Often Class 1.4.2
• Food & beverage: Typically Class 1.2.1 to meet food‑safety standards.
• Medical & pharmaceutical: Usually Class 0 to protect patient safety and product integrity.

Achieving and Maintaining Compliance

JHFOSTER offers end‑to‑end support—from evaluation and design to integration and ongoing maintenance—to ensure your compressed‑air system meets ISO 8573‑1 standards.

• Equipment selection: We help you choose the right compressor, dryer, and filter combination to achieve the required purity.
• Piping delivery system design: We recommend corrosion‑resistant materials and layout strategies that preserve air quality.
• Monitoring: Regular testing per ISO 8573‑1 Parts 2–9 guarantees continuous compliance.

Frequently Asked Questions

What is the difference between ISO and OSHA standards for compressed air?

OSHA focuses on workplace safety—setting limits for cleaning pressures (≤30 psig) and prohibiting PVC/CPVC piping due to burst risk. ISO 8573‑1, in contrast, specifies the purity and quality of the air itself.

Can I use PVC for compressed air piping?

No. PVC is prohibited by OSHA because it can swell and burst under high pressure. Metal piping—such as aluminum, copper, or stainless steel—provides the safety and corrosion resistance needed for clean air.

How often should I test my air quality?

Air quality sampling should occur at key points of use multiple times a year—typically quarterly or bi‑annually—to ensure accurate assessment and ongoing compliance.

Ensure Air Purity Compliance with JHFOSTER’s Expert Support

Don’t leave air purity to chance. Download JHFOSTER’s free ISO 8573‑1 PDF and contact a compressed‑air specialist today to select the right equipment and maintain compliance.

•
