Sinumerik 840D Alarm List

• 1000 System error %1
• 1001 System error %1
• 1002 System error %1
• 1003 Alarm pointer for this self-clearing alarm %1 is zero
• 1004 Alarm reaction to NCK alarm incorrectly configured
• 1005 Operating system error %1 parameter %2 %3 %4
• 1010 Channel %1 system error %2 action %3
• 1011 Channel %1 %3 %4 system error %2
• 1012 Channel %1 system error %2 %3 %4
• 1013 Channel %1 system error %2
• 1014 Channel %1 system error %2
• 1015 Channel %1 axis %2 system error %3
• 1016 Channel %1 axis %2 system error %3
• 1017 Channel %1 axis %2 system error %3
• 1018 Floating point arithmetic error in channel %1 task %2 station %3 FPU state %4 %4
• 1019 Floating point arithmetic error at address %3 in channel %1 task %2 FPU state %4
• 1030 System error in link module error code %1 error type %2
• 1031 Link module generated an unspecified error %1 NCU %2 %3 %4
• 1100 No valid firmware
• 1160 Assertion failed in %1: %2
• 2000 PLC sign-of-life monitoring
• 2001 PLC has not started up
• 2100 NCK battery warning threshold reached
• 2101 NCK battery alarm
• 2102 NCK battery alarm
• 2110 NCK temperature alarm
• 2120 NCK fan alarm
• 2130 5V/24V encoder or 15V D/A converter under voltage
• 2140 The actual service switch position forces a SRAM to be cleared at the next Power On (general reset active)
• 2190 Hardware plug-in module for communication with the digitizer missing
• 2192 No NCU link module exists, MD %1 reset
• 2193 “Safety Integrated” is not available for link axis %1.
• 2195 Channel %1 axis %2 high-speed punching/nibbling not possible via link
• 2196 Link axis active and $MN_MM_SERVO_FIFO_SIZE != %1
• 2900 Reboot is delayed
• 3000 Emergency stop
• 3001 Internal emergency stop
• 4000 Channel %1 machine data %2[%3] has gap in axis assignment
• 4001 Channel %1 axis %2 defined for more than one channel via machine data %3
• 4002 Channel %1 machine data %2[%3] assigns an axis not defined in channel
• 4003 Axis %1 incorrect assignment of master channel in machine data %2
• 4004 Channel %1 machine data %2 axis %3 defined repeatedly as geometry axis
• 4005 Maximum number of axes in channel %1 exceeded. Limit %2
• 4007 Axis %1 incorrect assignment of master NCU in machine data %2
• 4010 Invalid identifier used in machine data %1[%2]
• 4011 Channel %1 invalid identifier used in machine data %2[%3]
• 4012 Invalid identifier used in machine data %1[%2]
• 4013 Invalid NCU link configuration by machine data %1 = %2 , on NCU_1 = %3
• 4014 Axis %1 defined several times in %2
• 4016 Axis %1 already used by NCU %2
• 4017 Axis container %1, location %2 already used by NCU %3
• 4018 Axis container %1, location %2 not used by any channel
• 4019 Axis container %1 advance not allowed with current status of NCU %2
• 4020 Identifier %1 used several times in machine data %2
• 4021 Channel %1 identifier %2 used several times in machine data %3
• 4022 Axis container %3 switch not allowed: ext. zero offset active channel %1 axis %2
• 4023 Axis container %1 switch not allowed, axis container %2 switch active
• 4024 Invalid axis configuration due to missing axis container machine data
• 4025 Axis container %3 switch not allowed: master/slave active channel %1 axis %2
• 4026 Machine data %1[%2], link axis NC%3_AX%4 not used by any channel
• 4027 Notice: MD %1 was also changed for the other axes of axis container %2
• 4028 Notice! The axial MDs of the axes of the axis containers were matched.
• 4029 Notice: the axial MDs in axis container %1 will be matched on the next power-up
• 4030 Channel %1 axis identifier missing in machine data %2[%3]
• 4031 Channel %1 link axis %2 defined for more than one channel in machine data %3
• 4032 Channel %1 wrong identifier for facing axis in %2
• 4033 Notice: NCU link communication still not connected
• 4034 Local link axis %1 is not allowed for different interpolation cycle time = %2/%3
• 4035 Interpolation cycle from NCU%1 = %2 does not match NCU%3 = %4
• 4036 Wrong NCU link configuration by MD %1
• 4040 Channel %1 axis identifier %2 not consistent with machine data %3
• 4045 Channel %1 conflict between machine data %2 and machine data %3
• 4050 NC code identifier %1 cannot be reconfigured to %2
• 4060 Standard machine data loaded
• 4062 Backup data loaded
• 4065 Buffered memory was restored from backup medium (potential loss of data!)
• 4066 Buffered memory of FFS restored from backup medium (potential loss of data!)
• 4070 Normalizing machine data has been altered
• 4073 Compile cycle functions define machine data number %1 several times
• 4075 Machine data %1 (and maybe others) not altered due to missing permission level %2
• 4076 %1 Machine data could not be altered with permission level %2
• 4077 New value %1 of MD %2 not set. Requested %3 bytes too much %4 memory.
• 4080 Incorrect configuration of indexing axis in MD %1
• 4090 Too many errors during power-up
• 4100 System cycle time/scan time divider corrected for digital drive
• 4102 Default values for drive cycle times differ
• 4110 IPO factor increased to %1
• 4111 PLC cycle increased to %1 ms
• 4112 Servo cycle changed to %1 ms
• 4113 Sysclock cycle changed to %1 ms
• 4114 Error in DP cycle of SDB1000
• 4115 Time ratio communication to Ipo changed to %1
• 4150 Channel %1 invalid M function sub program call configured
• 4152 Illegal configuration of the “Block display with absolute values” function
• 4160 Channel %1 invalid M function number configured for spindle switchover
• 4170 Invalid M function number for channel synchronisation assigned
• 4180 Invalid M function number assigned to enable ASUP
• 4181 Channel %1 invalid assignment of an M auxiliary function number
• 4182 Channel %1 invalid M auxiliary function number in %2%3, MD reset
• 4183 Channel %1 M auxiliary function number %2 used several times (%3 and %4)
• 4184 Channel %1 illegally predefined auxiliary function in %2%3, MD reset
• 4185 Channel %1 illegal auxiliary function configured %2 %3 %4
• 4200 Channel %1 geometry axis %2 must not be declared a rotary axis
• 4210 Channel %1 spindle %2 declaration as rotary axis missing
• 4215 Channel %1 spindle %2 declaration as modulo axis missing
• 4220 Channel %1 spindle %2 declared repeatedly
• 4225 Channel %1 axis %2 declaration as rotary axis missing
• 4230 Channel %1 data alteration from external not possible in current channel state
• 4240 Runtime overflow for IPO cycle or position controller cycle, IP %1
• 4250 FastPlcCom functionality not available
• 4252 PLCIO read error: %1
• 4254 PLCIO write error: %1
• 4260 Machine data %1 illegal
• 4270 Machine data %1 assigns not activated NCK input/output byte %2
• 4275 Machine data %1 and %2 both assign the same NCK output byte no. %3 several times
• 4280 Assignment of NCK input/output byte via MD %1[%2] does not match hardware configuration
• 4282 Hardware of external NCK outputs assigned repeatedly
• 4285 Error on terminal block %1, error code %2
• 4290 Local P-bus sign-of-life monitoring
• 4291 Module in local P-bus slot %1 error codes %2 %3 %4 %2 %3 %4
• 4300 Declaration in MD %1 is not allowed for geometry axis/spindle %2.
• 4310 Declaration in MD %1 index %2 is not allowed.
• 4320 Axis %1 function %2 %3 and %4 not allowed
• 4334 Channel %1 The amount of fine correction in parameter %2 of the orientable toolholder %3 is too large
• 4336 Channel %1 orientable toolholder no. %2 for orientation transformation %3 does not exist
• 4338 Channel %1 invalid transformation type ‘%2’ in toolholder %3 for orientation transformer %4
• 4340 Channel %1 block %2 invalid transformation type in transformation no. %3
• 4341 Channel %1 block %2 no data set available for transformation no. %3
• 4342 Channel %1 invalid machine data for general 5-axis transformation error no. %2
• 4343 Channel %1 attempt made to change the machine data of an active transformation.
• 4345 Channel %1 invalid configuration in chained transformation no.%2
• 4346 Channel %1 invalid geoaxis assignment in machine data %2[%3]
• 4347 Channel %1 invalid channel axis assignment in machine data %2[%3]
• 4350 Channel %1 axis identifier %2 machine data %3 not consistent with machine data %4
• 4400 MD alteration will cause reorganisation of buffered memory (loss of data!)
• 4502 Channel %1 anachronism %2(%3) -> %4
• 5000 Communication job not executable %1
• 6000 Memory reorganized using standard machine data
• 6010 Channel %1 data block %2 not or not completely created, error code %3
• 6020 Machine data have been altered – now memory is reorganized
• 6030 Limit of user memory has been adapted
• 6035 Instead of %1 KB the system has only %2 KB of free user memory of type “%3”
• 6100 Error while creating %1, error number %2 %3
• 6401 Channel %1 tool change not possible: Empty location for tool %2 Duplo no. %3 on magazine %4 not available.
• 6402 Channel %1 tool change not possible. Magazine no. %2 not available
• 6403 Channel %1 tool change not possible. Magazine location number %2 on magazine %3 not available.
• 6404 Channel %1 tool change not possible. Tool %2 not available or not usable
• 6405 Channel %1 command %2 has invalid PLC acknowledge parameter %3 – identifier %4
• 6406 Channel %1 PLC acknowledge for command %2 is missing
• 6407 Channel %1 tool %2 cannot be placed in magazine %3 on location %4.Invalid definition of magazine!
• 6410 TO unit %1 tool %2 / Duplo no. %3 has reached its pre warning limit with D = %4
• 6411 Channel %1 tool %2 / Duplo no. %3 has reached its prewarning limit with D = %4
• 6412 TO unit %1 tool %2 / Duplo no. %3 has reached its monitoring limit with D = %4
• 6413 Channel %1 tool %2 / Duplo no. %3 has reached its monitoring limit with D = %4
• 6421 Channel %1 tool move not possible. Empty location for tool %2 Duplo no. %3 on magazine %4 not available.
• 6422 Channel %1 tool move not possible. Magazine no. %2 not available.
• 6423 Channel %1 tool move not possible. Location %2 on magazine %3 not available.
• 6424 Channel %1 tool move not possible. Tool %2 not available/not usable.
• 6425 Channel %1 tool %2 cannot be placed in magazine %3 on location %4. Invalid definition of magazine!
• 6430 Workpiece counter: overflow in table of monitored cutting edges.
• 6431 Function not allowed. Tool management/monitoring is not active.
• 6432 Function not executable. No tool assigned to tool holder/spindle
• 6433 Channel %1 block %2 %3 not available with tool management
• 6434 Channel %1 block %2 NC command SETMTH not allowed because tool holder function not active
• 6441 Writing of $P_USEKT not allowed.
• 6442 Channel %1 function not executable. No tool assigned to desired magazine/magazine location %2.
• 6450 Channel %1 tool change not possible. Invalid magazine location no. %2 in buffer magazine
• 6451 Channel %1 tool change not possible. No buffer magazine defined.
• 6452 Channel %1 tool change not possible. Tool holder/spindle number = %2 not defined.
• 6453 Channel %1 tool change not possible. No assignment between toolholder/spindle no. = %2 and buffer magazine location %3
• 6454 Channel %1 tool change not possible. No distance relation available.
• 6500 NC memory full
• 6510 Too many part programs in the NC memory
• 6520 The value of the machine data %1%2 is too low
• 6530 Too many files in directory
• 6540 Too many directories in the NC memory
• 6550 Too many subdirectories
• 6560 Data format not allowed
• 6570 NC memory full
• 6580 NC memory full
• 6600 NC card memory is full
• 6610 Too many files open on NC card
• 6620 NC card has incorrect format
• 6630 NC card hardware is defective
• 6640 NC card is not inserted
• 6650 Write protection of NC card is active
• 6660 ‘Flash File System’ option is not set
• 6670 NC card read active
• 6671 NC card write active
• 6690 Cycles from NC card cannot be copied to the passive file system.
• 6691 Cycles from the passive file system cannot be saved on the NC card
• 6692 Cycle %1 lost
• 6693 File %1 lost
• 6698 Unknown NC card (%1/%2). Writing not possible.
• 6700 Channel %1 value of the machine data %2%3 is too low
• 7000 Too many compile cycle alarms defined
• 7010 Range of MMC alarm numbers for compile cycles exceeded
• 7020 Compile cycle alarm number has not been defined
• 7100 Compile cycles VDI area: %1 byte for inputs and %2 byte for outputs. Maximum %3 bytes available.
• 7200 Problem with externally linked compile cycle %1 %2
• 7201 Assertion error in %1 line %2
• 7202 Missing option bit for %1: %2
• 8000 Channel %1 option ‘user interrupt programs’ not set
• 8010 Option ‘activation of more than %1 axes’ not set
• 8020 Option ‘activation of more than %1 channels’ not set
• 8021 Option ‘activation of more than %1 mode groups’ not set
• 8022 Option ‘activation of more than %1KB SRAM’ not set
• 8030 Channel %1 block %2 option ‘interpolation of more than 4 axes’ not set
• 8032 Option ‘activation of more than %1 link axes’ not set
• 8034 Option ‘activation of axis containers’ not set
• 8036 Option: it is not allowed to set different IPO cycles or position control cycles with NCU link.
• 8038 Option ‘activation of more than %1 lead link axes’ not set
• 8040 Machine data %1 reset, corresponding option is not set
• 8041 Axis %1: MD %2 reset, corresponding option not sufficient
• 8044 Option for IPO cycle time %1 ms not set
• 8045 Option for selected cycle settings not set
• 8080 %1 options are activated without setting the license key
• 8081 %1 options are activated that are not licensed by the license key
• 8082 The license key was entered three times, Power On required before next try.
• 8098 Invalid combination of options (%1)
• 8100 Channel %1 block %2: function not possible
• 10203 Channel %1 NC start without reference point
• 10207 Channel %1 error when selecting or deselecting the digitize function
• 10208 Channel %1 continue program with NC start
• 10209 Channel %1 internal NC stop after block search
• 10222 Channel %1 inter-channel communication not possible
• 10223 Channel %1: Command %2 is already occupied
• 10225 Channel %1: command denied
• 10299 Channel %1 Auto-Repos function is not enabled
• 10600 Channel %1 block %2 auxiliary function during thread cutting active
• 10601 Channel %1 block %2 zero velocity at block end point during thread cutting
• 10604 Channel %1 block %2 thread lead increase too high
• 10605 Channel %1 block %2 thread lead decrease too high
• 10607 Channel %1 block %2 thread with frame not executable
• 10610 Channel %1 axis %2 not stopped
• 10620 Channel %1 block %3 axis %2 at software limit switch %4
• 10621 Channel %1 axis %2 rests on software limit switch %3
• 10630 Channel %1 block %2 axis %3 at working area limit %4
• 10631 Channel %1 axis %2 rests at working area limit %3
• 10650 Channel %1 axis %2 incorrect gantry machine data, error code %3
• 10651 Channel %1 illegal gantry configuration. Error code %2
• 10652 Channel %1 axis %2 gantry warning threshold exceeded
• 10653 Channel %1 axis %2 gantry error threshold exceeded
• 10654 Channel %1 waiting for synchronization start of gantry group %2
• 10655 Channel %1 synchronization of gantry group %2 in progress
• 10656 Channel %1 axis %2 gantry alarm not yet used
• 10700 Channel %1 block %2 NCK protection zone %3 violated during automatic or MDA mode
• 10701 Channel %1 block %2 channel-specific protection zone %3 violated during automatic or MDA mode
• 10702 Channel %1 NCK protection zone %2 violated during manual mode
• 10703 Channel %1 channel-specific protection zone %2 violated during manual mode
• 10704 Channel %1 block %2 protection zone monitoring is not guaranteed
• 10706 Channel %1 NCK protection zone %2 reached with axis %3 during manual mode
• 10707 Channel %1 channel-specific protection zone %2 reached with axis %3 during manual mode
• 10710 Channel %1 block %2 conflict with centre less grinding
• 10720 Channel %1 block %3 axis %2 software limit switch %4
• 10721 Channel %1 block %3 axis %2 software limit switch %4
• 10730 Channel %1 block %3 axis %2 working area limitation %4
• 10731 Channel %1 block %3 axis %2 working area limitation %4
• 10740 Channel %1 block %2 too many empty blocks in WAB programming
• 10741 Channel %1 block %2 direction reversal with WAB infeed motion
• 10742 Channel %1 block %2 WAB distance invalid or not programmed
• 10743 Channel %1 block %2 WAB programmed several times
• 10744 Channel %1 block %2 no valid WAB direction defined
• 10745 Channel %1 block %2 WAB end position not clear
• 10746 Channel %1 block %2 block search stop for WAB
• 10747 Channel %1 block %2 retraction direction not defined for WAB
• 10748 Channel %1 block %2 illegal retract plane with WAB
• 10750 Channel %1 block %2 tool radius compensation activated without tool number
• 10751 Channel %1 block %2 danger of collision due to tool radius compensation
• 10752 Channel %1 block %2 overflow of local block buffer with tool radius compensation
• 10753 Channel %1 block %2 selection of the tool radius compensation only possible in linear block
• 10754 Channel %1 block %2 deselection of the tool radius compensation only possible in linear block
• 10755 Channel %1 block %2 selection of the tool radius compensation via KONT not possible at the current starting point
• 10756 Channel %1 block %2 deselection of the tool radius compensation via KONT not possible at the programmed end point
• 10757 Channel %1 block %2 changing the compensation plane while tool radius compensation is active not possible
• 10758 Channel %1 block %2 curvature radius with variable compensation value too small
• 10759 Channel %1 block %2 path is parallel to tool orientation
• 10760 Channel %1 block %2 helical axis is not parallel to tool orientation
• 10761 Channel %1 block %2 tool radius compensation for ellipse with more than one revolution not possible
• 10762 Channel %1 block %2 too many empty blocks between two traversing blocks with active tool radius compensation
• 10763 Channel %1 block %2 path component of the block in the compensation plane becomes zero
• 10764 Channel %1 block %2 discontinuous path with active tool radius compensation
• 10765 Channel %1 block %2 3D tool radius compensation not possible
• 10766 Channel %1 illegal change of surface orientation between block %2 and block %3
• 10767 Channel %1 block %2 processing with tilt angle unequal 0 not possible
• 10768 Channel %1 block %2 illegal tool orientation with 3D tool radius compensation
• 10769 Channel %1 block %2 Illegal surface normal vector with 3D tool radius compensation
• 10770 Channel %1 block %2 change of corner type due to change of orientation with active tool radius compensation
• 10771 Channel %1 block %2 overflow of local block buffer due to orientation smoothing
• 10772 Channel %1 block %2 illegal orientation change when activating or deactivating 3D face cutting
• 10773 Channel %1 illegal tool orientation in block %2 at inside corner with block %3
• 10774 Channel %1 illegal tool dimensions with face cutting in block %2
• 10775 Channel %1 illegal tool change with face cutting in block %2
• 10776 Channel %1 block%2 axis %3 must be geometry axis if tool radius compensation is active
• 10777 Channel %1 block %2 tool radius compensation: too many blocks with suppression of compensation
• 10778 Channel %1 block %2 preprocessing stop with active tool radius compensation
• 10779 Channel %1 block %2 preprocessing stop with active tool radius compensation
• 10780 Channel %1 block %2 preprocessing stop with active tool radius compensation
• 10781 Channel %1 block %2 illegal orientation of involute with tool radius compensation
• 10782 Channel %1 block %2 illegal curve type with tool radius compensation
• 10783 Channel %1 block %2 tool radius compensation type requires orientation transformation
• 10784 Channel %1 block %2 illegal tool for tool radius compensation with constraint surface
• 10790 Channel %1 block %2 plane change during linear programming with angles
• 10791 Channel %1 block %2 invalid angle during linear programming
• 10792 Channel %1 block %2 illegal interpolation type during linear programming with angles
• 10793 Channel %1 block %2 second block missing during linear programming with angles
• 10794 Channel %1 block %2 angle specification missing in second block during linear interpolation with angles
• 10795 Channel %1 block %2 end point specification during angle programming contradictory
• 10800 Channel %1 block %3 axis %2 is not a geometry axis
• 10805 Channel %1 block %2 repositioning after switch of geometry axes or transformation
• 10810 Channel %1 block %2 master spindle not defined
• 10820 Channel %1 rotary axis/spindle %2 not defined
• 10860 Channel %1 block %2 feedrate not programmed
• 10861 Channel %1 block %3 velocity of positioning axis %2 is zero
• 10862 Channel %1 block %2 master spindle also used as path axis
• 10870 Channel %1 block %2 facing axis not defined
• 10880 Channel %1 block %2 too many empty blocks between two traversing blocks when inserting chamfers or radii
• 10881 Channel %1 block %2 overflow of local block buffer when inserting chamfers or radii
• 10882 Channel %1 block %2 activation of chamfers or radii (non-modal) without traversing movement in the block
• 10883 Channel %1 block %2 chamfer or fillet has to be reduced
• 10890 Channel %1 block %2 overflow of local block buffer when calculating splines
• 10891 Channel %1 block %2 multiplicity of node is greater than its order
• 10900 Channel %1 block %2 no S value programmed for constant cutting speed
• 10910 Channel %1 block %2 excessive velocity of one path axis
• 10911 Channel %1 block %2 transformation prohibits to traverse the pole
• 10912 Channel %1 block %2 preprocessing and main run might not be synchronized
• 10913 Channel %1 block %2 negative feed profile is ignored
• 10914 Movement not possible while transformation active – in channel %1, block %2
• 10930 Channel %1 block %2 interpolation type not allowed in stock removal contour
• 10931 Channel %1 block %2 incorrect stock removal contour
• 10932 Channel %1 block %2 preparation of contour has been restarted
• 10933 Channel %1 block %2 contour program does not contain enough contour blocks
• 10934 Channel %1 block %2 array for contour segmentation is set too small
• 10940 Channel %1 block %2 curve table %3: delete/overwrite not possible
• 10941 Channel %1 block %2 curve table %3: NC memory full
• 10942 Channel %1 block %2 curve table %3: illegal instruction during definition
• 10943 Channel %1 block %2 curve table %3: direction reversal of lead value in the block not allowed
• 10944 Channel %1 block %2 curve table %3: illegal transformation
• 10945 Channel %1 block %2 curve table %3: illegal coupling of axes
• 10946 Channel %1 block %2 curve table %3: no contour defined
• 10947 Channel %1 block %2 curve table %3: contour not continuous
• 10948 Channel %1 block %2 curve table %3: position jump at end of period
• 10949 Channel %1 block %2 curve table %3: missing master axis motion
• 10950 Channel %1 calculation of arc length function too inaccurate
• 10951 Channel %1 block %2 curve table %3: following value period is zero
• 10955 Channel %1 block %2 curve table %3: missing master axis motion
• 10956 Channel %1 block %2 curve table %3: NC memory limit DRAM reached
• 10960 Channel %1 block %2 COMPCURV/COMPCAD and radius compensation cannot be used simultaneously
• 10961 Channel %1 block %2 maximum cubic polynomials are allowed on active radius compensation.
• 10962 Channel %1 block %2 function %3 not possible with path correction
• 12000 Channel %1 block %2 address %3 programmed repeatedly
• 12010 Channel %1 block %2 address %3 address type programmed too often
• 12020 Channel %1 block %2 illegal address modification
• 12030 Channel %1 block %2 invalid parameter or data type in %3
• 12040 Channel %1 block %2 expression %3 is not of data type ‘AXIS’
• 12050 Channel %1 block %2 DIN address %3 not configured
• 12060 Channel %1 block %2 same G group programmed repeatedly
• 12070 Channel %1 block %2 too many syntax-defining G functions
• 12080 Channel %1 block %2 syntax error in text %3
• 12090 Channel %1 block %2 unexpected parameter %3
• 12100 Channel %1 block %2 number of passes %3 not permissible
• 12110 Channel %1 block %2 block syntax cannot be interpreted
• 12120 Channel %1 block %2 G function not separately programmed
• 12130 Channel %1 block %2 illegal tool orientation
• 12140 Channel %1 block %2 functionality %3 not implemented
• 12150 Channel %1 block %2 operation %3 not compatible with data type
• 12160 Channel %1 block %2 range of values exceeded
• 12170 Channel %1 block %2 identifier %3 defined repeatedly
• 12180 Channel %1 block %2 illegal chaining of operators %3
• 12190 Channel %1 block %2 variable of type ARRAY has too many dimensions
• 12200 Channel %1 block %2 symbol %3 cannot be created
• 12210 Channel %1 block %2 string %3 too long
• 12220 Channel %1 block %2 binary constant %3 in string too long
• 12230 Channel %1 block %2 hexadecimal constant %3 in string too long
• 12240 Channel %1 block %2 tool orientation %3 defined repeatedly
• 12250 Channel %1 block %2 nested macro %3 not possible
• 12260 Channel %1 block %2 too many initialization values specified %3
• 12261 Channel %1 block %2 initialization of %3 not allowed
• 12270 Channel %1 block %2 macro identifier %3 already defined
• 12280 Channel %1 block %2 maximum macro length %3 exceeded
• 12290 Channel %1 block %2 arithmetic variable % 3 not defined
• 12300 Channel %1 block %2 call-by-reference parameter missing on subroutine call %3
• 12310 Channel %1 block %2 axis parameter missing on procedure call %3
• 12320 Channel %1 block %2 parameter %3 is no variable
• 12330 Channel %1 block %2 type of parameter %3 incorrect
• 12340 Channel %1 block %2 number of parameters too high %3
• 12350 Channel %1 block %2 parameter %3 no longer possible
• 12360 Channel %1 block %2 dimension of parameter %3 incorrect
• 12370 Channel %1 block %2 range of values %3 not permissible
• 12380 Channel %1 block %2 maximum memory capacity reached
• 12390 Channel %1 block %2 initialization value %3 cannot be converted
• 12400 Channel %1 block %2 field %3 element does not exist
• 12410 Channel %1 block %2 incorrect index type for %3
• 12420 Channel %1 block %2 identifier %3 too long
• 12430 Channel %1 block %2 specified index is invalid
• 12440 Channel %1 block %2 maximum number of formal arguments exceeded
• 12450 Channel %1 block %2 label defined twice
• 12460 Channel %1 block %2 maximum number of symbols exceeded with %3
• 12470 Channel %1 block %2 G function %3 is unknown
• 12475 Channel %1 block %2 invalid G function number %3 programmed
• 12480 Channel %1 block %2 subroutine %3 already defined
• 12490 Channel %1 block %2 access permission level %3 is not valid
• 12500 Channel %1 block %2 in this module %3 is not possible
• 12510 Channel %1 block %2 too many machine data %3
• 12520 Channel %1 block %2 too many tool parameters %3
• 12530 Channel %1 block %2 invalid index for %3
• 12540 Channel %1 block %2 Block is too long or too complex
• 12550 Channel %1 block %2 name %3 not defined or option not installed
• 12552 Channel %1 block %2 tool/magazine OEM parameter not defined. Option not set.Option not set.
• 12560 Channel %1 block %2 programmed value %3 exceeds allowed limits
• 12570 Channel %1 block %2 too many motion synchronous actions in %3
• 12571 Channel %1 block %2 %3 not permissible for motion synchronous action
• 12572 Channel %1 block %2 %3 only permissible for motion synchronous action
• 12580 Channel %1 block %2 %3 not permissible for assignment in motion synchronous action
• 12581 Channel %1 block %2 invalid read access to %3 while in motion synchronous action
• 12582 Channel %1 block %2 field index %3 incorrect
• 12583 Channel %1 block %2 variable %3 no system variable
• 12584 Channel %1 block %2 variable %3 cannot be read synchronously with motion
• 12585 Channel %1 block %2 variable %3 cannot be changed synchronously with motion
• 12586 Channel %1 block %2 motion synchronous action: type conflict in variable %3
• 12587 Channel %1 block %2 motion synchronous action: operation/function %3 not allowed
• 12588 Channel %1 block %2 motion synchronous action: address %3 not allowed
• 12589 Channel %1 block %2 motion synchronous action: variable %3 not allowed with modal ID
• 12590 Channel %1 block %2 global user data cannot be created
• 12600 Channel %1 block %2 invalid line checksum
• 12610 Channel %1 block %2 accessing single character with call-by-reference parameter not possible %3
• 12620 Channel %1 block %2 accessing this variable as single character not possible
• 12630 Channel %1 block %2 skip ID/label in control structure not allowed
• 12640 Channel %1 block %2 invalid nesting of control structures
• 12641 Channel %1 block %2 maximum nesting depth of control structures exceeded
• 12650 Channel %1 block %2 axis identifier %3 different in channel %4
• 12660 Channel %1 block %2 motion synchronous action: variable %3 reserved for motion synchronous actions and technology cycles
• 12661 Channel %1 block %2 technology cycle %3: no further subprogram call possible
• 12700 Channel %1 block %2 contour definition programming not allowed as modal sub program is active
• 12701 Channel %1 block %2 illegal interpolation type for contour definition active
• 12710 Channel %1 block %2 illegal language element in external language mode
• 12720 Channel %1 block %2 program number for macro call (G65/G66) missing
• 12722 Channel %1 block %2 multiple ISO_2/3 macro or cycle calls in the block
• 12724 Channel %1 block %2 no radius programmed for cylinder interpolation activation/deactivation
• 12726 Channel %1 block %2 illegal plane selection with parallel axes
• 12728 Channel %1 block %2 distance for double turret not set
• 12730 Channel %1 block %2 no valid transformation machine data parametrized
• 12740 Channel %1 block %2 modal macro call %3 not possible
• 14000 Channel %1 block %2 illegal end of file
• 14001 Channel %1 block %2 illegal end of block
• 14009 Channel %1 block %2 illegal program path %3
• 14010 Channel %1 block %2 invalid default parameter in subroutine call
• 14011 Channel %1 block %2 program %3 not existing or will be edited
• 14012 Channel %1 block %2 maximum subroutine level exceeded
• 14013 Channel %1 block %2 number of subroutine passes invalid
• 14014 Channel %1 selected program %3 not available or will be edited
• 14015 Channel %1 block %2 program %3 is not enabled
• 14016 Channel %1 block %2 error when calling the subroutine via M/T function
• 14017 Channel %1 block %2 syntax error when calling the subroutine via M function
• 14020 Channel %1 block %2 wrong value or wrong number of parameters on function or procedure call
• 14021 Channel %1 block %2 wrong value or wrong number of parameters on function or procedure call
• 14025 Channel %1 block %2 motion synchronous action: illegal modal ID
• 14026 Channel %1 block %2 motion synchronous action: invalid polynomial number in the FCTDEF command
• 14030 Channel %1 block %2 combine OSCILL and POSP during oscillation with in feed motion
• 14033 Channel %1 block %2 involute: no end point programmed
• 14034 Channel %1 block %2 involute: angle of rotation too large
• 14035 Channel %1 block %2 involute: start point invalid
• 14036 Channel %1 block %2 involute: end point invalid
• 14037 Channel %1 block %2 involute: radius invalid
• 14038 Channel %1 block %2 involute not definable: end point error
• 14039 Channel %1 block %2 involute: end point programmed several times
• 14040 Channel %1 block %2 error in end point of circle
• 14045 Channel %1 block %2 error in tangential circle programming
• 14048 Channel %1 block %2 wrong number of revolutions in circle programming
• 14050 Channel %1 block %2 nesting depth for arithmetic operations exceeded
• 14051 Channel %1 block %2 arithmetic error in part program
• 14060 Channel %1 block %2 invalid skip level with differential block skip
• 14070 Channel %1 block %2 memory for variables not sufficient for subroutine call
• 14080 Channel %1 block %2 jump destination %3 not found
• 14082 Channel %1 block %2 label %3 program section not found
• 14085 Channel %1 block %2 instruction not allowed
• 14088 Channel %1 block %2 axis %3 doubtful position
• 14090 Channel %1 block %2 illegal D number
• 14091 Channel %1 block %2 illegal function, index %3 %3
• 14092 Channel %1 block %2 axis %3 is wrong axis type
• 14093 Channel %1 block %2 path interval <= 0 with polynominal interpolation
• 14094 Channel %1 block %2 polynominal degree greater than 3 programmed for polynominal interpolation
• 14095 Channel %1 block %2 radius for circle programming too small
• 14096 Channel %1 block %2 illegal type conversion
• 14097 Channel %1 block %2 string cannot be converted to AXIS type
• 14098 Channel %1 block %2 conversion error: no valid number found
• 14099 Channel %1 block %2 result in string concatenation too long
• 14100 Channel %1 block %2 orientation transformation not available
• 14101 Channel %1 block %2 orientation transformation not active
• 14102 Channel %1 block %2 polynominal degree greater than 5 programmed for orientation vector angle
• 14110 Channel %1 block %2 Euler angles and orientation vector components programmed
• 14111 Channel %1 block %2 Euler angles, orientation vector and transformation axes programmed
• 14112 Channel %1 block %2 programmed orientation path not possible
• 14113 Channel %1 block %2 programmed lead angle too large
• 14114 Channel %1 block %2 programmed tilt angle too large
• 14115 Channel %1 block %2 illegal definition of workpiece surface
• 14116 Channel %1 block %2 absolute orientation programmed while ORIPATH is active
• 14117 Channel %1 block %2 no angle or direction of the cone programmed
• 14118 Channel %1 block %2 no end orientation programmed
• 14119 Channel %1 block %2 no intermediate orientation programmed
• 14120 Channel %1 block %2 plane determination for programmed orientation not possible
• 14122 Channel %1 block %2 angle and direction of the cone programmed
• 14123 Channel %1 block %2 nutation angle of the cone too small
• 14124 Channel %1 block %2 start tangent for orientation is zero
• 14125 Channel %1 block %2 programmed rotation is not possible
• 14129 Channel %1 block %2 orientation angles and orientation vector components programmed
• 14130 Channel %1 block %2 too many initialization values given
• 14131 Channel %1 block %2 orientation axes and lead/tilt angles programmed
• 14132 Channel %1 block %2 orientation axes incorrectly configured
• 14133 Channel %1 block %2 G code for orientation definition not allowed
• 14134 Channel %1 block %2 G code for orientation interpolation not allowed
• 14140 Channel %1 block %2 position programming without transformation not allowed
• 14144 Channel %1 block %2 PTP movement not allowed
• 14146 Channel %1 block %2 CP or PTP movement without transformation not allowed
• 14148 Channel %1 illegal reference system for Cartesian manual traverse
• 14150 Channel %1 block %2 illegal tool carrier number programmed or declared (MD)
• 14151 Channel %1 block %2 illegal tool carrier rotation
• 14152 Channel %1 block %2 tool carrier: invalid orientation. Error code: %3
• 14153 Channel %1 block %2 unknown tool carrier type: %3
• 14154 Channel %1 block %2 The amount of fine correction in parameter %3 of the orientable tool holder %4 is too large
• 14155 Channel %1 block %2 invalid base frame definition for tool carrier offset
• 14156 Channel %1 toolholder selection error at reset
• 14157 Channel %1 block %2 illegal interpolation type with MOVT
• 14159 Channel %1 block %2 more than two angles programmed with ROTS or AROTS
• 14160 Channel %1 block %2 tool length selection without geometry axis specification
• 14165 Channel %1 block %2 active T number does not match selected tool
• 14170 Channel %1 block %2 illegal interpolation type with tool length compensation
• 14180 Channel %1 block %2 H number is not defined
• 14185 Channel %1 block %2 D number is not defined
• 14190 Channel %1 block %2 H number with G49
• 14195 Channel %1 block %2 D number with G49
• 14197 Channel %1 block %2 D number and H number programmed simultaneously
• 14198 Channel %1 block %2 illegal change of tool direction with tool offset
• 14199 Channel %1 block %2 illegal plane change for tool with diameter component
• 14200 Channel %1 block %2 negative polar radius
• 14210 Channel %1 block %2 polar angle too large
• 14250 Channel %1 block %2 negative pole radius
• 14260 Channel %1 block %2 pole angle too large
• 14270 Channel %1 block %2 pole programmed incorrectly
• 14280 Channel %1 block %2 polar coordinates programmed incorrectly
• 14290 Channel %1 block %2 poly nominal degree greater than 5 programmed for poly nominal interpolation
• 14300 Channel %1 block %2 overlaid handwheel motion activated incorrectly
• 14310 Handwheel %1 configuration incorrect or inactive
• 14400 Channel %1 block %2 tool radius compensation active at transformation switchover
• 14401 Channel %1 block %2 transformation not available
• 14402 Channel %1 block %2 spline active at transformation change
• 14403 Channel %1 block %2 preprocessing and main run might not be synchronized
• 14404 Channel %1 block %2 illegal parametrization of transformation
• 14410 Channel %1 block %2 spline active at geometry axis changeover
• 14411 Channel %1 block %2 tool radius compensation active at geometry axis changeover
• 14412 Channel %1 block %2 transformation active at geometry axis changeover
• 14413 Channel %1 block %2 fine tool correction: changeover geometry/channel axis not allowed
• 14414 Channel %1 block %2 GEOAX function: incorrect call
• 14415 Channel %1 block %2 tangent control: changeover geometry/channel axis not allowed
• 14420 Channel %1 block %2 index axis %3 frame not allowed
• 14500 Channel %1 block %2 illegal DEF or PROC instruction in the part program
• 14510 Channel %1 block %2 PROC instruction missing on subroutine call
• 14520 Channel %1 block %2 illegal PROC instruction in data definition section
• 14530 Channel %1 block %2 EXTERN and PROC instruction do not correspond
• 14600 Channel %1 block %2 reload buffer %3 cannot be established
• 14601 Channel %1 block %2 reload buffer could not be deleted
• 14602 Channel %1 block %2 timeout during EXTCALL
• 14610 Channel %1 block %2 compensation block not possible
• 14650 Channel %1 block %2 SETINT instruction with invalid ASUP input
• 14660 Channel %1 block %2 SETINT instruction with invalid priority
• 14700 Channel %1 block %2 timeout during command to interpreter
• 14701 Channel %1 block %2 number of available NC blocks reduced by %3
• 14710 Channel %1 block %2 error in initialization sequence in function %3
• 14720 Channel %1 block %2 axes for centerless transformation not available
• 14730 Channel %1 block %2 conflict at activation of centerless transformation
• 14740 Channel %1 block %2 no tool data available for centerless grinding
• 14745 Channel %1 block %2 centerless grinding not active
• 14750 Channel %1 block %2 too many auxiliary functions programmed
• 14751 Channel %1 block %2 resources for motion synchronous actions not sufficient (code: %3)
• 14752 Channel %1 block %2 DELDTG | STOPREOF conflict
• 14753 Channel %1 block %2 motion synchronous actions with illegal interpolation type
• 14754 Channel %1 block %2 motion synchronous actions and wrong feed type
• 14755 Channel %1 block %2 motion synchronous actions without traverse motion
• 14756 Channel %1 block %2 motion synchronous action and wrong value
• 14757 Channel %1 block %2 motion synchronous action and wrong type
• 14758 Channel %1 block %2 programmed value not available
• 14759 Channel %1 block %2 motion synchronous action and wrong axis type
• 14760 Channel %1 block %2 auxiliary function of a group programmed repeatedly
• 14761 Channel %1 block %2 motion synchronous action: DELDTG function not allowed with active tool radius compensation
• 14762 Channel %1 block %2 too many PLC variables programmed
• 14763 Channel %1 block %2 too many link variables programmed
• 14764 NCU link cannot transfer all link variables immediately
• 14765 NCU link cannot transfer all link variables
• 14766 NCU link is heavily loaded, impending memory shortage
• 14767 Machine data matching via NCU link not complete
• 14770 Channel %1 block %2 auxiliary function programmed incorrectly
• 14780 Channel %1 block %2 unreleased option used
• 14790 Channel %1 block %2 axis %3 programmed by PLC
• 14800 Channel %1 block %2 programmed path speed less or equal to zero
• 14810 Channel %1 block %2 negative axis speed programmed for positioning axis %3
• 14811 Channel %1 block %2 incorrect value range for acceleration of axis/spindle %3
• 14812 Channel %1 block %2 SOFTA not available for axis %3
• 14815 Channel %1 block %2 negative thread lead change programmed
• 14820 Channel %1 block %2 negative value for maximum spindle speed programmed with constant cutting speed
• 14821 Channel %1 block %2 error in selection or deselection of GWPS
• 14822 Channel %1 block %2 incorrect programming of GWPS
• 14823 Channel %1 block %2 error on selection or deselection of tool monitoring
• 14824 Channel %1 block %2 conflict with GWPS
• 14840 Channel %1 block %2 incorrect value range for constant cutting speed
• 14900 Channel %1 block %2 center point and end point programmed simultaneously
• 14910 Channel %1 block %2 invalid angle of aperture for programmed circle
• 14920 Channel %1 block %2 intermediate point of circle incorrect
• 15000 Channel %1 block %2 channel-sync instruction using illegal mark
• 15010 Channel %1 block %2 program coordination instruction with invalid channel number
• 15020 Channel %1 block %2 CHANDATA instruction cannot be executed. Channel %3 is not active
• 15021 Channel %1 block %2 CHANDATA instruction with invalid channel number
• 15025 CHANDATA(%2): channel is not active. Channel data will be ignored.
• 15030 Channel %1 block %2 different measurement system settings
• 15100 Channel %1 block %2 REORG abort caused by log file overflow
• 15110 Channel %1 block %2 REORG not possible
• 15150 Channel %1 block %2 reload from external aborted
• 15160 Channel %1 block %2 wrong preprocessing configuration
• 15165 Channel %1 block %2 error when translating or interpreting PLC Asup %3
• 15166 Channel %1 user system asup _N_ASUP_SPF not available
• 15170 Channel %1 block %2 program %3 could not be compiled
• 15171 Channel %1 block %2 compiled program %3 older than the relevant subroutine
• 15175 Channel %1 block %2 program %3. Interfaces could not be built
• 15180 Channel %1 block %2 program %3 cannot be executed as INI file
• 15185 Channel %1 %2 errors in INI file
• 15190 Channel %1 block %2 not enough free memory for subroutine call
• 15300 Channel %1 block %2 invalid number-of-passed-blocks during block search
• 15310 Channel %1 block %2 file requested during block search is not available
• 15320 Channel %1 block %2 invalid block search command
• 15330 Channel %1 block %2 invalid block number as search target
• 15340 Channel %1 block %2 invalid label as search target
• 15350 Channel %1 block %2 search target not found
• 15360 Channel %1 illegal target of block search (syntax error)
• 15370 Channel %1 target of block search not found
• 15380 Channel %1 block %2 illegal incremental programming in axis %3
• 15390 Channel %1 block %2 %3 not executed during block search
• 15395 Channel %1 master-slave not executable during block search
• 15400 Channel %1 block %2 selected initial init file does not exist
• 15410 Channel %1 block %2 initialization file contains invalid M function
• 15420 Channel %1 block %2 instruction in current mode not allowed
• 15450 Channel %1 block %2 compiled program cannot be stored
• 15460 Channel %1 block %2 syntax error with modal function
• 15500 Channel %1 block %2 illegal angle of shear
• 15700 Channel %1 block %2 illegal cycle alarm number %3
• 15800 Channel %1 block %2 wrong starting conditions for CONTPRON/CONTDCON
• 15810 Channel %1 block %2 wrong array dimension for CONTPRON/CONTDCON
• 15900 Channel %1 block %2 touch probe not allowed
• 15910 Channel %1 block %2 touch probe not allowed
• 15950 Channel %1 block %2 no traverse motion programmed
• 15960 Channel %1 block %2 no traverse motion programmed
