Mazak PLC Alarm Guide: Comprehensive Error Codes for CNC Machinists

Mazak plc alarm list for cnc machinists. Alarm List for the Mazak INTEGREX 300/400-II

For other Mazak alarm lists visit following pages.

• Mazak System/Drive error ( No. 1 – No. 99, No. 1000 – No. 1099 )
• Mazak CNC machine control error ( No. 100 – No. 199, No. 1100 – No. 1199 )
• Mazak PLC machine control error ( No. 200 – No. 399, No. 1200 – No. 1399 )
• Mazak CNC screen operation error ( No. 400 – No. 499, No. 1400 – No. 1499 )
• Mazak I/O error ( No. 500 – No. 599, No. 1500 – No. 1599 )
• Mazak MAZATROL program error ( No. 600 – No. 699, No. 1600 – No. 1699 )
• Mazak MAZATROL program error ( No. 700 – No. 799, No. 1700 – No. 1799 )
• Mazak EIA/ISO program error ( No. 800 – No. 899, No. 1800 – No. 1899 )
• Mazak EIA/ISO program error ( No. 900 – No. 999, No. 1900 – No. 1999 )
• Mazak Interference error ( No. 2100 – No. 2199 )

Mazak PLC Alarm List

• 200 THERMAL TRIP (EMERGENCY STOP)
• 201 BREAKER TRIP
• 202 HYDRAULIC PRESSURE DOWN
• 203 AIR PRESSURE DOWN
• 204 SPINDLE CONTROLLER MALFUNCTION
• 205 MILLING CONTROLLER MALFUNCTION
• 206 OPEN FRONT DOOR (EMERGENCY STOP)
• 211 NOT OPERATED MCODE SIMULTA.
• 212 CHUCK OPEN/CLOSE SWITCH MALF.
• 213 ILLEGAL DESIGNATED TOOL No.
• 215 CHUCK SYSTEM MALFUNCTION
• 218 CHUCKING TYPE NOT SELECTED
• 220 TURRET POSITION SENSOR MALF.
• 221 TURRET CLAMP SENSOR MALFUNCTION
• 224 CHUCK SENSOR MALFUNCTION
• 225 FRONT DOOR SENSOR MALFUNCTION
• 231 TOOL EYE POSITION SENSOR MALF.
• 234 TOOL CLAMP SENSOR MALFUNCTION
• 236 PARTS-CATCHER SENSOR MALF.
• 243 MEASURING CONTROLLER MALF.
• 245 BAR-FEEDER CONTROLLER MALF.
• 248 EXTERNAL CONTROLLER (No.1) MALF.
• 250 SPINDLE START MISOPERATION
• 251 MILLING MOTOR ROTATION PROHIB.
• 252 AXIS MOVE MISOPERATION
• 253 OVERLOAD DETECTION
• 256 TURRET ROTATION PROHIBITED
• 257 ILLEGAL M-CODE
• 258 TNo. MISMATCH
• 259 MODE CHANGE IMPOSSIBLE
• 260 SLIDEWAY LUBRICATION ALARM
• 261 HEAD LUBRICATION ALARM
• 264 THERMAL TRIP X5 (SINGLE BLOCK)
• 267 BALL SCREW X44C LUBRICATION ALARM
• 270 SPINDLE ORIENT EXCEED TIME
• 272 TURRET INDEX EXCEED TIME
• 275 ROBOT SERVICE EXCEED TIME
• 276 ATC CYCLE EXCEED TIME
• 279 PARTS CATCHER CYCLE EXCEED TIME
• 282 CHUCK CLAMP EXCEED TIME
• 286 FRONT DOOR EXCEED TIME
• 292 SENSOR MALFUNCTION No. 3
• 293 SENSOR MALFUNCTION No. 4
• 297 CHUCK PRESSURE DOWN
• 300 START COND. ERR. (DOOR OPEN)
• 301 START COND. ERR. (TUR UNCLAMP)
• 302 START COND. ERR. (EXT RESET)
• 303 START COND. ERR. (EXT FEED HOLD)
• 308 C/S ERROR (TOOL EYE EXTEND)
• 310 C/S ERROR (TNo.MISMATCH)
• 311 C/S ERROR (TAIL STOCK QUILL)
• 312 C/S ERROR (PTCATCHER EXTEND)
• 313 C/S ERROR (C/S QUILL COMMAND)
• 320 TOOL UNCLAMP IMP. (M-SP ROT.)
• 321 MODE CHANGE IMPOSSIBLE (DURING ATC CYCLE)
• 322 RAPID MODE IMP. (ORIGIN RET UNF)
• 324 DIFF. MODE (ORIGIN RET UNFIN.)
• 325 TL. EYE EXT. IMP.
• 326 T/S QUILL EXT. IMP.
• 327 NOT IN ATC START POSITION
• 329 CHUCKING SELECTION PROHIBITED
• 340 CONDITION No.1 MISSING
• 341 CONDITION No.2 MISSING
• 361 TAIL ALARM
• 365 CARRIER CONTROLER MALFUNCTION
• 366 SHIFTER CONTROLER MALFUNCTION
• 374 OPERATING SWITCH FAULT
• 375 MOTOR & SERVO TURNING OFF ERR.
• 376 MAIN POWER TURNING OFF MALFUNCTION
• 377 COOLANT LEVEL LOW
• 378 HIGH PRESSURE PUMP THERMAL TRIP
• 379 TANK PRESSURE LOW
• 381 CONDITION MISSING (SET UP SWITCH)
• 382 COOLANT SYSTEM MALF.
• 383 ATC ALM: CARRIER&SHIFT. POS. MALF.
• 385 START COND. ERR. (Z-AXIS POS.)
• 386 ATC STOP
• 390 TOOL ON INTERFER ALARM
• 391 LD/ULD/ACHG CONDITION ALARM
• 392 MAGAZINE MANUAL INTERR.
• 394 ATC CONTROLLER MALF.
• 395 CHECK SENSOR MALF. (SEE D199)
• 397 MAGAZINE DOOR INTERLOCK
• 398 MAGAZINE COVER OPEN
• 399 MAINTE./ADJUST PARAM. ON
