Osai SSL Command: Set Spindle Speed Limits with G96
Osai 10 Series command SSL is used with G96 to set the maximum rpm that the spindle is allowed to run during CSS.
Programming
SSL=value
Parameters
| Parameter | Description |
|---|---|
| value | Is a value that can be programmed directly with a decimal number or indirectly with an E parameter. |
Examples
SSL = 2000 ;Assign a spindle speed limit of 2000 rpm E32 = 1500 SSL = E32 ;Assign a spindle speed limit of 1500 rpm
Important
Make sure you enter this value in the part program prior to entering G96 blocks.
