Designing for Binder Jetting: 5 Essential Tips for Reliable 3D Prints

Binder Jetting is among the most widely adopted powder‑bed 3D printing technologies. Success hinges on a design approach that aligns with its unique process characteristics. Unlike conventional manufacturing, Binder Jetting demands distinct considerations to unlock its full potential. This guide distills the key design strategies that will help you achieve optimal results.

Binder Jetting – How It Works

Binder Jetting deposits a liquid binder onto successive layers of fine powder, binding the particles together. Similar to Selective Laser Sintering, the surrounding unbound powder acts as a self‑supporting matrix, eliminating the need for external support structures. Because the part never reaches the high temperatures typical of fused deposition or powder bed fusion, issues such as warping or cracking are largely avoided. Additionally, Binder Jetting machines offer larger build volumes, enabling the production of sizeable components or the nesting of multiple parts on a single build plate.

5 Design Tips for Binder Jetting

1. Wall Thickness

Choosing the correct wall thickness is critical. Too thin and the part may deform during printing or crack when removed; too thick and material waste increases. A minimum wall thickness of 2 mm is recommended for reliable builds.

2. Escape Holes

Since the process uses powder, any internal cavities must be vented. Incorporate at least two escape holes with a minimum diameter of 0.5 mm to prevent trapped powder, which can add unwanted weight and alter mechanical properties.

3. Unsupported Walls and Edges

Green (uncured) parts are fragile and usually require post‑processing to strengthen them. Design unsupported walls to be at least 3 mm thick and limit unsupported edge lengths to no more than 20 mm to reduce the risk of damage during handling.

4. Part Orientation

Surface finish is heavily influenced by build orientation. Place fine features on the upward (X/Y) plane to minimize stair‑stepping. Consider part consolidation—combining several parts into a single build—to optimize material use and build time.

5. Topology Optimisation

Binder Jetting excels at fabricating complex geometries. Use topology optimisation algorithms to remove unnecessary material, thereby reducing weight and cost while preserving structural performance.

In Summary

Binder Jetting offers unique advantages but also specific design constraints. By applying these five principles—wall thickness, escape holes, unsupported geometry, orientation, and topology optimisation—you can enhance print reliability, part performance, and overall design efficiency.
