As a way of thanking the 15,000 students on our courses at Udemy. Cim-Team organizes the E3.fundamentals course. See all the details in this article:

1. Division and Content

The new reformulation of the E3.fundamentals course has the following division and some of the contents covered are:

E3.schematic



• Start of a new project;
• Insertion of sheets and automated renumbering;
• Insertion of standard devices, terminals, wires, symbols, text template, automatic cross-references and signal names.
• Link between sheet cross-references and manual reference insertion;
• Creation of device assemblies in the design and assignment inheritance;
• Device secondary symbols;

Continues after ad

Try NOW the industry-leading E-CAE E3.series tool in the world with technical training courses!

Click on the banner below:

E3.panel Plus

• Creation of Dynamic Panels for the Panel;
• Dynamic Mounting Panel Box;
• Creation of the assembly sheet;
• Dynamic Channel, Slopes and Holes;
• Dynamic Rails, Rail Type, Slopes and Holes;
• Standard Component for Gutter and Rail.

E3.cable

• Insertion of connector devices, blocks and hierarchical blocks;
• Assign names in blocks;
• Reposition texts;
• Split and merge multi-row and single-line connector views;
• Graphical documentation of connector master view;
• Use of hierarchical block connection ports;
• Creating sheets for hierarchical blocks;

E3.formboard



• Block name;
• Insertion of connectors into blocks;
• Device designations for block connectors;
• Start of electrical connections between the counter pieces of connectors;
• Connection methods;
• Definition of line colors and thicknesses.

---

Take the E3.fundamentals Course TODAY using the button below:
