First CNC Program: Step-by-Step CNC Machining Guide
Submit by: Tanveer
Drawing/Image
CNC Program
O1234 (Program Number) N5 G90 G20 (ABSOLUTE COORDINATE. IN INCHES) N10 M06 T3 (TOOLCHANGE TO TOOL #3) N15 M03 S1250 (SPINDLE ON CW AT 1250RPM) N20 G00 X1 Y1 (RAPID OVER TO X1 Y1) N25 Z0.1 (RAPID DOWN TO Z0.1) N30 G01 Z-0.125 F5 (FEED DOWN TO Z-0.125 AT 5IPM) N35 X3 Y2 F10 (FEED DIAGONALLY TO X3 Y2 AT 10IPM) N40 G00 Z1 (RAPID UP TO Z1) N45 X0 Y0 (RAPID OVER TO X0 Y0) N50 M05 (SPINDLE OFF) N55 M30 (PROGRAM END)
