Titanium is a versatile metal with a melting point of 1,668 °C. Below 882 °C it crystallizes in a hexagonal close‑packed (α) structure; above that temperature it adopts a body‑centered cubic (β) structure. By alloying with elements such as aluminum, vanadium, molybdenum, or niobium, manufacturers can shift the α/β transition temperature and tailor the phase composition, producing a range of titanium alloys with distinct performance characteristics.

At room temperature, titanium alloys are classified into three main families based on their dominant matrix structure: α alloys, α + β alloys, and β alloys.

1. α Titanium Alloys

These are single‑phase alloys that remain in the α‑solid solution at all service temperatures. They exhibit excellent wear resistance, strong oxidation resistance, and a stable microstructure. Typical applications include aerospace fasteners, medical implants, and high‑temperature structural components. Although α alloys retain their strength between 500 °C and 600 °C, they cannot be further strengthened by conventional heat treatment and their room‑temperature yield strength is generally lower than that of β alloys.

2. β Titanium Alloys

Beta alloys consist of a single β‑phase solid solution. They possess high strength even before any heat treatment. After quenching and aging, their room‑temperature yield strength can reach 1,372–1,666 MPa, making them suitable for high‑strength, low‑weight applications. However, β alloys suffer from poor high‑temperature stability, limiting their use above 400 °C.

3. α + β Titanium Alloys

These two‑phase alloys combine the best of both worlds: they offer good structural stability, toughness, and plasticity while maintaining high temperature performance. They can be processed by hot‑working, then quenched and aged to increase strength by 50–100 %. Typical service temperatures range from 400 °C to 500 °C, but they are less thermally stable than pure α alloys.

Among the three families, α alloys are prized for their machinability, followed by α + β alloys, while β alloys are the most difficult to machine.

4. Key Uses of Titanium Alloys

Titanium alloys are valued for their high specific strength, low density, excellent toughness, and corrosion resistance. They are widely used in aerospace: from aircraft engine compressors to rocket, missile, and high‑speed aircraft structural parts. Their density is about 60 % that of steel while offering comparable strength, and they resist seawater corrosion and perform well at cryogenic temperatures.

In spacecraft, titanium’s high specific strength and corrosion resistance enable the construction of pressure vessels, fuel tanks, fasteners, instrument straps, frames, and rocket shells. The Space Shuttle, manned spacecraft, and Earth‑orbit satellites frequently use titanium alloy plate‑welded components for weight savings and reliability.

Conclusion

Understanding the three primary titanium alloy categories—α, β, and α + β—helps engineers select the right material for specific performance demands. For deeper insight into titanium alloys or other refractory metals, visit Advanced Refractory Metals (ARM). Headquartered in Lake Forest, California, ARM is a leading manufacturer and supplier of high‑quality refractory metals, including tungsten, molybdenum, tantalum, rhenium, titanium, and zirconium.
